Fingertip Pulse Oximete with 2.8" color OLED display real-time clock model AH-60F

Fingertip Pulse Oximete with 2.8" color OLED display real-time clock model AH-60F

    • Fingertip Pulse Oximete with 2.8" color OLED  display real-time clock model AH-60F
    • Fingertip Pulse Oximete with 2.8" color OLED  display real-time clock model AH-60F
    • Fingertip Pulse Oximete with 2.8" color OLED  display real-time clock model AH-60F
    • Fingertip Pulse Oximete with 2.8" color OLED  display real-time clock model AH-60F
    • Fingertip Pulse Oximete with 2.8" color OLED  display real-time clock model AH-60F
    • Fingertip Pulse Oximete with 2.8" color OLED  display real-time clock model AH-60F
  • Fingertip Pulse Oximete with 2.8" color OLED  display real-time clock model AH-60F

    Product Details:

    Place of Origin: GUANDONG,CHINA
    Brand Name: HUGE OEM ODM
    Certification: CE RoHS
    Model Number: AH-60F

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: 86-95USD/PC
    Packaging Details: box
    Delivery Time: 5-7days
    Payment Terms: TT /paypay/ Western Union
    Supply Ability: 10000pcs/weeks
    Contact Now
    Detailed Product Description



    Pulse oximeter

    Model:AH-60F



    Major Features

    *Small in volume,light in weight and convenient in carrying
    *Operation of the product is simple ,low power consumption
    *Operation menu for the function setting
    *SpO2 value display
    *Pulse rate value display, bar graph display
    *Pulse waveform display
    *PI Display
    *Screen brightness can be changed
    *A pulse rate sound indication
    *With measured data overruns limits and low-voltage alarm function, the upper/down alarm range is adjustable
    *Battery capacity indication
    *Low-voltage indication: low-voltage indicator appears before working abnormally which is due to low-voltage ,and with alarm function
    *Real-time data can be transmitted to computers
    *With clock function
    *Review function
    *With data record function of multiuser, continuous record about 24 hours data for each user, and the record data can be uploaded to computer
    *Touch key operation and locking touch key function
    *It can be connected with adult,child,infant oximeter probe
    *Wireless communication function



    Main performance

    *Display Mode: 2.8" TFT Color display
    *Screen Resolution: 320*240
    *SpO2 Measuring Range: 0%~100%, (the resolution is 1%).
    *Accuracy: 70%~100%: ±2% ,Below 70% unspecified.
    *PR Measuring Range: 30bpm~250bpm, (the resolution is 1bpm)
    *Accuracy: ±2bpm or ±2% (select larger)
    *Measurement Performance in Weak Filling Condition:
    *SpO2 and pulse rate can be shown correctly when pulse-filling ratio is 0.4%. SpO2 error is ±4%, pulse rate error is ±2 bpm or ±2% (select larger).
    *Resistance to surrounding light: The deviation between the value measured in the condition of man-made light or indoor natural light and that of darkroom is less than ±1%.
    *Voltage: DC 3.6V~4.2V
    *Power Supply: Voltage 3.7 rechargeable lithium battery × 1
    *Battery working hour: 10 hours
    *Battery working life: Charge and discharge no less than 500 times.
    *Safety Type: Interior Battery, BF Type



    Accessories

    *Sell in standard:
    *A user manual
    *A power adapter (GTM41076-0605;CMS0105)
    *A data line
    *A disk (PC software)
    *An oximeter probe


    Sell in addition:
    *Other oximeter probe(Refer to probe application instruction for details and notice renewal)



    Physical Identity
    *Dimension: 94.25(L) × 55.32(W) × 9.6(H) mm
    *Weight: About 80g (with a lithium battery)





    Under the order, please confirm what the use of probe:

    1, animal probe

    2, infants probe

    3, adult probe
