| Place of Origin: | China |
| Brand Name: | HUGE OEM ODM |
| Certification: | CE RoHS |
| Model Number: | AH-50A |
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | 10-60USD/PC |
| Packaging Details: | box |
| Delivery Time: | within 5 working days after get payment |
| Payment Terms: | TT /paypay/ Western Union |
| Supply Ability: | 10000pcs/weeks |
Major Features
*Integrated with SpO2 probe and processing display module
*Small in volume,light in weight and convenient in carrying
*Operation of the product is simple , low power consumption
*SpO2 value display
*Pulse rate value display, bar graph display
*Pulse waveform display
*Battery capacity indication
*With backlight
*Automatically power off function: when the device is under the state of measuring interface . it will automatically power
off within 5 seconds if the finger falls out of probe
Main performance
Display Mode: 1.3" LCD display
Screen Resolution: 128*64
SpO2 Measuring Range: 0%~100%, (the resolution is 1%).
Accuracy:70%~100%: +/-2% , Below 70% unspecified.
PR Measuring Range: 30bpm~250bpm, (the resolution is 1bpm)
Accuracy: +/-2bpm or +/-2% (select larger)
Measurement Performance in Weak Filling Condition:
SpO2 and pulse rate can be shown correctly when pulse-filling ratio is 0.4%. SpO2 error is +/-4%, pulse rate error is +/-2 bpm or +/-2% (select larger).
Resistance to Surrounding light: The deviation between the value measured in the condition of man-made light or indoor natural light and that of darkroom is less than +/-1%.
Power Consumption:Smaller than 40mA.
Voltage: DC 3.0V
Power Supply: 1.5V (AAA size) alkaline batteries x 2
Battery Working Hour: The minimum continually work time is 15 hours , theoretical number is 28 hours.
Safety Type: Interior Battery, BF Type
Accessories
Sell in standard:
*A hanging rope
*A user manual
Physical Identity
Dimension: 65(L) x 35(W) x 40 (H) mm
Weight: About 75g (with the batteries)
Qualification
Passed CE
