Passed FDA and CE Dual-color OLED AH-50D

Passed FDA and CE Dual-color OLED AH-50D

    • Passed FDA and CE Dual-color OLED AH-50D
    • Passed FDA and CE Dual-color OLED AH-50D
    • Passed FDA and CE Dual-color OLED AH-50D
    • Passed FDA and CE Dual-color OLED AH-50D
  • Passed FDA and CE Dual-color OLED AH-50D

    Product Details:

    Place of Origin: China
    Brand Name: HUGE OEM ODM
    Certification: CE RoHS
    Model Number: AH-50D

    Payment & Shipping Terms:

    Minimum Order Quantity: 1PC
    Price: 8-30USD/PC
    Packaging Details: box
    Delivery Time: within 5 working days after get payment
    Payment Terms: TT /paypay/ Western Union
    Supply Ability: 10000pcs/weeks
    Contact Now
    Detailed Product Description

    Major Features

    *Integrated with Spo2 probe and processing display module
    *Small in volume , light in weight and convenient in carrying
    *Operation of the product is simple, low power consumption
    *SpO2 value display
    *Pulse rate value display, bar graph display
    *Pulse waveform display
    *The display mode can be changed
    *Screen brightness can be changed
    *Low-voltage indication: low-voltage indicator appears before working abnormally which is due to low-voltage
    *Automatically power off function: when the device is under the state of measuring interface . it will automatically power off within 5 seconds if the finger falls out of probe
    *Display format can be saved after power off

    Main performance

    Display Mode: 0.96"Dual-color OLED display(blue and yellow)
    Screen Resolution: 128*64
    SpO2 Measuring Range: 0%~100%, (the resolution is 1%).
    Accuracy: 70%~100%: +/-2% ,Below 70% unspecified.
    PR Measuring Range: 30bpm~250bpm, (the resolution is 1bpm)
    Accuracy: +/-2bpm or +/-2% (select larger)
    Measurement Performance in Weak Filling Condition:
    SpO2 and pulse rate can be shown correctly when pulse-filling ratio is 0.4%. SpO2 error is +/-4%, pulse rate error is +/-2 bpm or +/-2% (select larger).
    Resistance to Surrounding Light: The deviation between the value measured in the condition of man-made light or indoor natural light and that of darkroom is less than +/-1%.
    Power Consumption: less than30mA
    Voltage: DC 3.0V
    Power Supply: 1.5V (AAA size) alkaline batteries * 2
    Battery Working Hour : The minimum continually work time is 20 hours, theoretical number is 36 hours.
    Safety Type: Interior Battery, BF Type

    Accessories

    Sell in standard:
    *A hanging rope
    *A user manual

    Physical Identity
    Dimension: 57(L) * 31(W) * 32(H) mm
    Weight: About 50g (with the batteries)

    Qualification

    Passed FDA and CE
