ECG/TEMP/NIBP/SpO2/RESP/PR multi-parameter patient monitor M8

ECG/TEMP/NIBP/SpO2/RESP/PR multi-parameter patient monitor M8

    • ECG/TEMP/NIBP/SpO2/RESP/PR multi-parameter patient monitor M8
    • ECG/TEMP/NIBP/SpO2/RESP/PR multi-parameter patient monitor M8
    • ECG/TEMP/NIBP/SpO2/RESP/PR multi-parameter patient monitor M8
    • ECG/TEMP/NIBP/SpO2/RESP/PR multi-parameter patient monitor M8
    • ECG/TEMP/NIBP/SpO2/RESP/PR multi-parameter patient monitor M8
  • ECG/TEMP/NIBP/SpO2/RESP/PR multi-parameter patient monitor M8

    Product Details:

    Place of Origin: China
    Brand Name: HUGE OEM ODM
    Certification: CE RoHS
    Model Number: M8

    Payment & Shipping Terms:

    Minimum Order Quantity: 1PCS
    Price: USD $800-1200/pcs
    Packaging Details: box
    Delivery Time: within 5 working days after get payment
    Payment Terms: TT /paypay/ Western Union
    Supply Ability: 10000pcs/month
    Contact Now
    Detailed Product Description





    ECG/TEMP/NIBP/SpO2/RESP/PR multi-parameter patient monitor M8





    Brief introduction:

    Patient monitor is a kind of instrument or system which is used to measure and control

    patients physiological parameters, which can be compared with known settings, if they

    are higher than know settings, the system will alarm.





    Features:

    • 6 Standard parameters: ECG, TEMP, NIBP, SpO2, RESP, PR

    • 8 inch high resolution color screen

    • Real time S-T segment analysis, pace-maker detection

    • Indication of incorrect manipulation and malfunction analysis

    • Patient info input management function

    • Large volume of tabular and praphic trends information storage and easy to recall

    • Capture 2-hour dynamic trend

    • Various interfaces:standard screen,trend screen,oxyCRG screen,big front screen

    • Up to 400 groups NIBP list,60 alarm event records recall, 7-day trend chart in storage.

    • Up to 2 hours working capacity of built-in rechargeable

    lithium battery

    • Unique accessory management cabinet

    • Networking capacity

    ETCO2, cart, wall shelf are optional



    Parameters:



    ECG



    Lead Mode 3-lead and 5-lead are optional

    Lead Selection I, II, III, avR, avL, avF, V

    Wave 5-lead: 2 channels

    3-lead: 1channel

    Gain ×2.5mm/mV, ×5.0mm/mV, ×10mm/mV,

    ×20mm/mV

    HR Measuring and Alarm Range

    Range 15 ~ 300 bpm

    Accuracy ±1% or ±1bpm, which is greater

    Alarm Accuracy ±2bpm

    Resolution 1 bpm

    ST Segment Monitoring Measuring and Alarm Range -0.6 mV~ + 0.8 mV
    Alarm Available
    Review Available

    Scan Speed for ECG

    Waveform is adjustable

    12.5mm/s accuracy ±10%

    25mm/s accuracy±10%

    50mm/s accuracy±10%

    Respiration



    Method R-F(RA-LL) Impedance

    Differential Input Impedance >2.5 MΩ

    Measuring Impedance Range 0.3~5.0Ω

    Baseline Impedance Range 100Ω– 2500Ω

    Bandwidth 0.3 ~ 2.5 Hz

    Resp. Rate



    Measuring and Alarm Range 0~120rpm

    Resolution 1 rpm

    Measuring Accuracy ±2 rpm

    Alarm Accuracy ±3rpm

    Apnea Alarm 10 ~ 40 S

    NIBP

    Method Oscillometry

    Mode Manual, Auto, continuous

    Measuring Interval in AUTO Mode 1 /2 /3 /4 /5/ 10/ 15/ 30 /60 /

    90/120/240/480/960 Min

    Measuring Period in Continuous Mode 5 Min

    Measuring and Alarm Range 10~270mmHg

    Alarm Type SYS, DIA, MEAN

    Resolution



    Pressure 1mmHg

    Cuff Pressure ±3 mmHg

    Accuracy ±10% or ±8mmHg, which is greater

    Over-pressure Protection:

    Adult Mode 315±10 mmHg

    Pediatric Mode 265±10 mmHg

    Neonatal Mode 155±10 mmHg

    SpO2

    Measuring Range 0 ~ 100 %

    Alarm Range 0 ~ 100 %

    Resolution 1 %

    Accuracy 70% ~ 100% ±2%

    0% ~ 69% unspecified

    Pulse Rate(PR)



    Measuring and Alarm Range 0~250bpm

    Resolution 1bpm

    Measuring Accuracy ±2bpm or ±2%, which is greater

    Alarm Accuracy ±2bpm

    TEMP

    Channel dual-channel

    Measuring and Alarm Range 0 ~ 50°C

    Resolution 0.1°C

    Accuracy ±0.1°C

    Actualization Interval about 1 Sec.

    Average Time Constant < 10 Sec.

    Alarm responding Time ≤2min






    ECG/TEMP/NIBP/SpO2/RESP/PR multi-parameter patient monitor M8





    Packaging & Delivery

    Packaging Details: Packing: 1 unit/carton
    1* Patient monitor
    reusable Spo2 sensor (1 pc);
    ECG cable and leadwire (1 pc);
    NIBP cuff and tube (1 pc);
    Built-in lithium battery (1 pc)
    1*English user manual (1pc)
    Delivery Detail: Shipped in 7 days after payment





    Competitive Advantage:



    Biggest manufacturer in China

    In stock supplies

    1 year Warranty

    100% quality guarante before shipment out

    Nice after-sale service
