Mini Multi Fuction Contec Patient Monitor For Medical Treatment

Mini Multi Fuction Contec Patient Monitor For Medical Treatment

small and hot sell multi fuction contec patient monitor

Quick Detail:

Patient Monitor adopts Oscillometry for NIBP measuring, Photoelectric Oxyhemoglobin Inspection Technology combining Capacity Pulse Scanning & Recording Technology for SpO2 measuring. Systolic Pressure(SYS), Diastolic Pressure(DIA), Mean Pressure(MAP), SpO2 and Pulse rate(PR) can be accurately measured.

Description:

NIBP:

* Method: Oscillometry

* Modes: Manual/Auto/Comtinuous

* Auto measure time:Adjustable

* Measurement rang:10-270mmHg

ECG:

* Lead mode:3-lead or 5-lead

* Lead selection:I;II;III;avR;avL;avF;V

* Heart rate range:Adult:15-300bpm;Pediatric/Neonatal:15-300bpm

* ECG waveform: 2 channals

* Accuracy: ± 1 bpm or ±1%

* S-T segment detection Measurement rang :-0.2mv~2.0mv

* Alarm:Yes,audible and visual alarm,alarm events review

* High resolution 12.1"color TFT display

* Lightweight,compact and portable

* ECG,APO2,NIBP,RESP,2-TEMP,PR

* Optional:2-IBP,ETCO2,And thermal printer

* Bulit-in rechargeable lithium battery

* ECG waveforms of 7-leads display on the same screen

* 72-hours graphic and tabular trends of all parameters

* 72 alarm events of all parameters recall

* 32 seconds full-disclosure waveform review

* 500 NIBP measurement date can be storage and recall

* Date and waveforms color be adjustable

* Arrhythmia analysis and S-T segment analysis

* Suitable for adult,pediatric and neonatal patient

SPO2

* Measurement range:0-100%

* Accyracy:70-100%, ±2% 0-69%,upspecified

Pulse rate

* Range:20-254bpm

* Accuracy: ±3bpm

Respiration

* Method:RA-LL impedance

* Range:Adult:0-120rpm;pediatric/neonatal:0-150rpm

* Apnca alarmYes

Temperature

* Range:0-50℃

* Apnca: 0.1℃

* Channal:Dual-Channal

Applications:

Compact appearance, comprehensive functions, simple and convenient operation, which is applicable for hospitals, community medical treatment and family.

Specifications:

NIBP monitoring
Measurement method: Oscillometry
Measurement mode: manual/auto/continuous.
Auto measurement interval: adjustable from 1 to 255 minutes.
Resolution: 1mmHg.
Accuracy: Maximum Mean deviation≤±5mmHg, Maximum Standard deviation≤8mmHg.
Self-check function.
Overpressure protection: double protection for software and hardware.

Competitive Advantage:

Good service .

Professonal delievery
